Steel C Z roof purlin cold bending machine

Basic Info

Model No.ZT-005

Brandzhongtuo

Drive ModeChain

Hydraulic Motor Power5.5kw

Material Of Shafts45# Steel With Tempering

Number Of Rollers16 Rollers

Main Power15kw

Material Of BladesGcr12MoV Quenched

Voltage380V/50HZ3Phase (as Customer`s Request)

Material Of RollersGCr15MoV

Diameter Of ShaftsΦ76mm

NameRoll Forming Machine For C Purlin & Z Purlin

Additional Info

PackagingAs customer's need

Productivity15-20m/min

TransportationOcean,Land,Air

Place of OriginChina(mainland)

Supply Ability30 sets/month

CertificateCE,ISO,SGS,IAF,CNAS.

HS Code84552210

PortTianjin,Qingdao,Guangzhou

Payment TypeL/C,T/T,D/P

IncotermFOB,CIF

Product Description

Steel C Z roof purlin cold Bending Machine


One machine can produce different sizes of purlines.

cz adjustable machine

Main Technical Specifications:
Material: Carbon steel
Material Thickness:1.5-3mm
Landscape orientation adjustment range of Hole distance : 45-500m
Length of purlin: >3m
Forming Stations: 17 Main rollers
Leveling Stations: 7
Feeding Stations: 2
Main Power: 15KW
Machine Diameter: About 12500mm(L)x2300mm(W)x1600mm (H) ( including main motor )
Weight of machine: about 15 Ton

cz adjustable machine
One machine can produce different C/Z Purlins through simple manual st adjustment, when to produce different profiles, no need to change the forming rollers. In the process, machine adopt automatic control model, it can auto punch, cut, forming based on inputting length of purlin, portrait hole distance, quantity, etc datas.

C/Z purlin roll former make up of decoiler, feeding, leveling, 2 sets hydraulic punching device, hydraulic cutting, speediness interchangeable forming machine, PLC control system, hydraulic stations, run out tables.
cz adjustable machine
This line main forming drive adopt reducer motor and frequency conversion control, speed control-

Product application of C shape Purlin Roll Forming Machine

They are widely used as the supporter of roof and wall in large-scale and mid-scale construction, such as factory, warehouse, garage, exhibition center, cinema, theatre, garden and so on.

Our Metal CZ shape Purlin Roll Forming Machine`s advantages

1. Anti-rust roller: Cr12 mould steel with quenched treatment, long life time.
2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.
3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.
4. High precision: shafts for rollers are tooled by grinding machine at least twice. Rollers are CNC processed to ensure precision performance.
5. People originate: introduced Mitsubishi PLC with touch screen. Friendly man-machine interaction.
6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.
7. All-in-house source: We are "All-in-house source" factory to ensure quality and delivery of your machines.
8. Long life: Ensure you our produce machine`s lifetime more than 15 years.

It is quick and easy to operate the machine, and beautiful appearance, high production efficiency, forming speed up to 20m/min.
cz adjustable machine

The advantage of our roll forming machine :


1.Good quality: We have a professional designer and experienced engineer team.And

the raw material and accessories we use are good.

2.Good service: we provide the technical support for whole life of our machines.

3.Guarantee period: within one year since the date of finishing commissioning. The guarantee covers all the electric, mechanic and hydraulic parts in the line except for the easy-worn parts.

4.Easy operation:All machine cotrolling by PLC computer controlling systerm.

5.Elegant apperance:Protect the machine from rust and the painted colour can be customized

6.Reasonable price:We offer the best price in our industry.
